Binocular Head Biological Microscope 03B-B6IBM100
Product1
Product2
Product3

Binocular Head Biological Microscope 03B-B6IBM100

Lab Expo Binocular Head Biological Microscope 03B-B6IBM100 has flat field infinity corrected planachromatic objectives, providing FN22 crisp images. This microscope is optimally designed to see the smallest specimen in crisp optical view and contrast. Multiple lenses can be attached, which gives this microscope a magnification that can range from 4x to 100x.

$2,357.00 $ 1964

Binocular Head Biological Microscope 03B-B6IBM100 - Specifications

Nosepiece 5-places revolver nosepiece
Head Binocular head
Objective Oil IOS infinity Plan-achromatic Phase Contrast objectives: PH 10x - PH 40x
Eyepiece n.2 eyepieces WF 10x/22
Lighting System Led adjustable lighting system 3 Watt

Binocular Head Biological Microscope 03B-B6IBM100 - Key Features

  • WF10x/22 eyepieces with diopter correction +/-5D
  • Nosepiece: 5-places revolver for quick objective change
  • LED illumination system: adjustable intensity 3W power supply
  • Condenser height adjustment for numerical aperture control
  • Phase contrast objectives PH10x and PH40x included
  • Field number FN22 provides wide flat field viewing

Binocular Head Biological Microscope 03B-B6IBM100 - Applications

FunctionImplementation
Clinical diagnostics labs3 Watt LED lighting supports clear specimen visualization
Quality control testingWF 10x/22 eyepieces enable detailed sample inspection
Research laboratories5-places revolver nosepiece allows rapid objective switching
Educational institutionsFN22 crisp images facilitate student learning observations
Industrial material analysisPhase contrast objectives PH 10x - PH 40x enhance translucent structure viewing

Binocular Head Biological Microscope 03B-B6IBM100 - Catalog

Binocular Head Biological Microscope 03B-B6IBM100 Catalog
