Binocular Head Biological Microscope 03B-BHM100

Binocular Head Biological Microscope 03B-BHM100

Lab Expo Binocular Head Biological Microscope 03B-BHM100 is optimally designed to see the smallest specimen in crisp optical view and contrast. Multiple lenses can be attached, which gives this microscope a magnification that can range from 4x to 100x. The objective lenses have short working distances with high apertures.

$2,515.00 $ 2096

Binocular Head Biological Microscope 03B-BHM100 - Specifications

Nosepiece 4-places revolver nosepiece
Head Binocular head
Objective Oil Achromatic objectives A 4x-10x-40x-100x
Eyepiece n.2 eyepiece WF 10x/18
Lighting System Halogen adjustable lighting system 6v/20watt

Binocular Head Biological Microscope 03B-BHM100 - Key Features

  • Halogen adjustable lighting system 6V20W with variable intensity control
  • Achromatic objectives A4x10x40x100x for high aperture magnification
  • WF10x18 eyepieces with wide field viewing and diopter adjustment
  • Four-place revolver nosepiece enabling rapid objective lens exchange
  • Binocular head design providing stereoscopic viewing and ergonomic positioning

Binocular Head Biological Microscope 03B-BHM100 - Applications

FunctionImplementation
Biological specimen viewing4x-100x magnification enables detailed cellular observation
Clinical sample analysisWF 10x/18 eyepieces provide wide-field diagnostic evaluation
Research laboratory work4-place revolver nosepiece supports rapid objective switching
Quality control inspectionHalogen 6V/20W lighting ensures consistent specimen illumination
Educational training sessionsBinocular head design allows comfortable prolonged examination

Binocular Head Biological Microscope 03B-BHM100 - Spare Parts

Wide field eyepiece WF10x (18)
Wide field eyepiece WF10x (18) F.T. focusable with measure graticule
Wide field eyepiece WF16x (11)
Objective Sp4x / 0,10 -160 /
Objective Sp 10x / 0,25 -160 / 0,17
Objective Sp 20x / 0,40 -160 / 0,17
Objective Sp 40x / 0,65 -160 / 0,17
Objective PA 60x / 0,85-160 / 0,17
Objective Sp HI 100x /1,25-160 / 0,17


Binocular Head Biological Microscope 03B-BHM100 - Catalog

Binocular Head Biological Microscope 03B-BHM100 Catalog
