Trinocular Head Biological Microscope 03B-TMB200

Trinocular Head Biological Microscope 03B-TMB200

Lab Expo Trinocular Head Biological Microscope 03B-TMB200 is primarily designed for observing cells, tissues and other biological specimens. Multiple lenses can be attached, which gives this microscope a magnification that can range from 4x to 100x. This microscope comes with fully coated glass optics and advanced features, with objective lenses having short working distances with high apertures.

$3,667.00 $ 3056

Trinocular Head Biological Microscope 03B-TMB200 - Specifications

Nosepiece 4-places revolver nosepiece
Head Trinocular Head
Objective Oil Achromatic objectives A 4x-10x-40x-100x
Eyepiece n.2 eyepieces WF 10x/18
Lighting System Halogen adjustable lighting system 6v/20watt

Trinocular Head Biological Microscope 03B-TMB200 - Key Features

  • Halogen adjustable lighting system 6v20watt
  • Eyepieces WF10x18 dual configuration
  • Four places revolver nosepiece mechanism
  • Trinocular head with vertical phototube

Trinocular Head Biological Microscope 03B-TMB200 - Applications

FunctionImplementation
Clinical diagnostics100x oil objective enables detailed cell morphology analysis
Research laboratoriesWF 10x/18 eyepieces support extended observation sessions
Quality control labs4-place nosepiece allows rapid magnification switching
Educational institutionsTrinocular head facilitates simultaneous viewing and documentation
Industrial inspectionHalogen 6V/20W lighting provides consistent specimen illumination

Trinocular Head Biological Microscope 03B-TMB200 - Spare Parts

Wide field eyepiece WF10x (18)
Wide field eyepiece WF10x (18) F.T. focusable with measure graticule
Wide field eyepiece WF16x (12)
Objective A 4x / 0,10-160 / -
Objective A 10x / 0,25 -160 / 0,17
Objective A 20x / 0,40 -160 / 0,17
Objective A 40x / 0,65 -160 / 0,17
Objective A 60x / 0,80 -160 / 0,17
Objective A HI 100x /1,25-160 / 0,17

Trinocular Head Biological Microscope 03B-TMB200 - Catalog

Trinocular Head Biological Microscope 03B-TMB200 Catalog

Related Biological Microscope

Lab Expo Biological Microscopes are structured around compound optical pathways to deliver high-resolution imaging for cellular and tissue analysis. This biological compound microscope supports multi-objective magnification with infinity-corrected optics and plan achromatic lenses for flat-field clarity. Stable stage mechanics, ergonomic binocular or trinocular viewing, and controlled illumination enable accurate observation for research, education, and clinical laboratory workflows.
