Lab Expo Biological Microscope LE-BMI103 is a binocular microscope with 30º inclined head and a backward nosepiece. Equipped with coarse and fine focus adjustments for sharp imaging and easy operation. Integrated with an ergonomic structure for extended use in various lab environments. Built illumination system provides consistent lighting for routine microscopic analysis. Our Biological Microscope is ideal for research institutes and educational laboratories for everyday biological studies.
$1,997.00 $ 1664
| Optical System | Infinite optical system |
| Viewing Head | Siedentopf Binocular viewing head, interpupillary distance range 48-75 mm, Inclined at 30º |
| Eyepiece | Wide Field Eyepiece WF10X/F.N. 22 mm |
| Nosepiece | Backward quadruple nosepiece |
| Objective | Infinite high contrast chromatic free full plan, Objectives: 4x, 10x, 40x, 100x |
| Stage | Double-layer mechanical stage: 216×150 mm, Graphite surface Moving range: 75×55 mm |
| Focusing | Coaxial coarse & fine adjustment, Fine division 0.001 mm, Coarse stroke 37.7 mm/Rotation, Fine stroke 0.1 mm/Rotation, Moving range 24 mm |
| Condenser | Abbe N.A. 1.25 condenser with Diaphragm |
| Illumination | External Illumination 3W /LED (Kohler) |
| Dimension | 530×325×390 mm |
| Net weight | 7 Kg |
| Gross weight | 9 Kg |
Function Implementation Routine biological studies 4x, 10x, 40x, 100x objectives enable detailed specimen analysis Educational laboratories WF10X eyepiece with 22 mm field number supports comfortable viewing Research institutes Infinite optical system provides chromatic-free imaging for precision work Quality control labs Double-layer mechanical stage with 75×55 mm movement allows precise sample positioning Clinical settings Abbe N.A. 1.25 condenser with diaphragm ensures optimal illumination contrast
Lab Expo Biological Microscopes are structured around compound optical pathways to deliver high-resolution imaging for cellular and tissue analysis. This biological compound microscope supports multi-objective magnification with infinity-corrected optics and plan achromatic lenses for flat-field clarity. Stable stage mechanics, ergonomic binocular or trinocular viewing, and controlled illumination enable accurate observation for research, education, and clinical laboratory workflows.
