FTIR Spectrometer LE-FTI101

Name: FTIR Spectrometer LE-FTI101
Brand: Labexpo
SKU: LE-FTI101
Rating: 4.7 (838 reviews)

Lab Expo FTIR Spectrometer LE-FTI101 offers a wide spectral range of 350 to 7800 cm⁻¹ to enable comprehensive analysis across the mid-infrared region. It operates with a scanning speed of 2 mm/s to deliver consistent measurements. Equipped with an air-cooled ceramic infrared light source for long-lasting performance. Integrated with DLATGS detector to provide high sensitivity. Our FTIR Spectrometer ensure high accuracy, stability, and efficiency for precise operation.

$21,744.00 $ 18120

FTIR Spectrometer LE-FTI101 - Specifications

Spectral Range	350 to 7800cm⁻¹ (Mid-Infrared Region)
Resolution Ratio	Better than 1.0 cm⁻¹
Wave Number Accuracy	0.01 cm⁻¹
Signal-to-Noise Ratio (SNR)	45,000:1 (P-P value, at ~2100 cm⁻¹, 4 cm⁻¹ resolution, 1 min data collection)
Detector	DLATGS
Light Source	Air-Cooled Ceramic Infrared Light Source
Beam Splitter	60 mm, Multi-Layer Coated KBr with Moisture-Proof Coating
Laser	VCSEL Laser
Scanning Speed	2 mm/s
Baseline Straightness	≤ 0.1% T
Aperture Ratio	1/3.2
Sample Beam Diameter	10 mm
Beam Diameter	30 mm
Interferometers	Automatic calibration
Environmental Temperature	15 to 28 ℃
Relative Humidity	< 65% (non-condensing)
Cleaning Function	Yes
Data Transmission	USB 2.0
Operating System	Windows 10 and above
Working Voltage	AC220V, DC12V, 40W
External Dimensions	590 × 390 × 190 mm
Sample Room Size	200 × 260 × 160 mm
Weight	26 kg

FTIR Spectrometer LE-FTI101 - Key Features

Seismic resistance with 0.1C resolution
Diverse testing across 350 to 7800cm⁻¹ range
Multi-layer coated KBr beam splitter at 60mm
Dust and moisture prevention with desiccant visual window

FTIR Spectrometer LE-FTI101 - Applications

Function	Implementation
Quality control labs	45,000:1 SNR ensures precise material verification
Clinical diagnostics	350 to 7800 cm⁻¹ range enables biomolecular analysis
Research laboratories	±0.01 cm⁻¹ wave number accuracy supports compound identification
Industrial testing	2 mm/s scanning speed allows rapid sample screening
Educational institutions	USB 2.0 data transmission facilitates student lab integration

FTIR Spectrometer LE-FTI101 - Standard Accessories

Supporting English software

AC power adapter and cable

USB data cable

Standard calibration sheet (polystyrene)

1 set of supporting tools

Color changing silicone

Transmission test attachments

Reflection test attachments

FTIR Spectrometer LE-FTI101 - Optional Accessories

Solid package accessory

Liquid package accessory

ATR accessory

FTIR Spectrometer LE-FTI101 - Catalog

FTIR Spectrometer LE-FTI101 Catalog
