IR Carbon and Sulphur Analyzer 39-CSA102

Lab Expo IR Carbon and Sulphur Analyzer 39-CSA102 is a unit for determination of sulphur and carbon equipped with two treatment units including a high frequency induction burner and flexible temperature settings with automatic control. With an analysis time of 25 to 60 seconds and 10 to 30 °C, the multi-shielded isolation circuit prevents the machine for high frequency interference. High speed 32-bit sampling improves sensitivity and accuracy.

$36,720.00 $ 30600

IR Carbon and Sulphur Analyzer 39-CSA102 - Specifications

Carbon measurement 0.000001 % to 99.99999 %
Sulphur measurement 0.000001 % to 99.99999 %
Sampling per second 32 times
Relative humidity < 80 %
Room temperature 10 ~ 30 °C
Sensitivity 0.1 ppm
Carbon detection pool Can add low carbon pool
Sulphur detection pool Can add high sulphur pool
Analysis time 35 seconds ( can be set 25 to 60 seconds )
Weighing precision 0.0001 g
Power ≥ 2.5 kV
Voltage 220 V
Oscillation frequency 20 MHz
Frequency 18 Hz

IR Carbon and Sulphur Analyzer 39-CSA102 - Key Features

  • Frequency setting at 18 Hz provides consistent operational timing control
  • Weighing precision of 0.0001 g enables microgram-level mass determination
  • Carbon measurement range from 0.000001% to 99.99999% covers trace to bulk levels
  • Relative humidity maintained below 80% for optimal environmental stability
  • Sensitivity rated at 0.1 ppm detects minimal analyte concentrations reliably

IR Carbon and Sulphur Analyzer 39-CSA102 - Applications

FunctionImplementation
Quality control labs0.1 ppm sensitivity detects trace sulphur levels
Clinical research facilities35 seconds analysis time enables rapid sample throughput
Industrial material testingWeighing precision 0.0001 g ensures accurate carbon quantification
Healthcare diagnostics labsSampling per second 32 times supports high-frequency data acquisition
Environmental monitoring sitesRoom temperature 10 ~ 30 °C allows operation in varied conditions

IR Carbon and Sulphur Analyzer 39-CSA102 - Catalog

IR Carbon and Sulphur Analyzer 39-CSA102 Catalog

Related IR Carbon and Sulphur Analyzer

Lab Expo IR Carbon and Sulphur Analyzer units are designed for infrared-based elemental determination in metallurgical, mining, and industrial analysis workflows. Systems support carbon measurement from 0.000001% to 99.99999% and sulphur measurement from 0.000001% to 99.99999% with analytical precision up to RSD ≤ 0.5% for carbon and ≤ 1% for sulphur. High-speed sampling configurations process up to 32 measurements per second, supporting rapid composition analysis and material quality verification.
